Key specs
Ram 2500/3500 (Pick-up) 2500/3500 Crew Cab I (facelift 2013) 2014,2015,2016,2017,2018
What is the body type, RAM 2500/3500 Crew Cab I (facelift 2013) Power Wagon 6.4 Hemi V8 (410 Hp) 4x4 Automatic 2014?
Pick-up, 4 Doors, 44717 Seats
How much power, RAM 2500/3500 Crew Cab I (facelift 2013) Power Wagon 6.4 Hemi V8 (410 Hp) 4x4 Automatic 2014?
410 Hp @ 5600 rpm.
63.9 Hp/l
What is the engine size, RAM 2500/3500 Crew Cab I (facelift 2013) Power Wagon 6.4 Hemi V8 (410 Hp) 4x4 Automatic 2014?
6417 cm3
391.59 cu. in.
How many cylinders, RAM 2500/3500 Crew Cab I (facelift 2013) Power Wagon 6.4 Hemi V8 (410 Hp) 4x4 Automatic 2014?
8,
V-engine
What is the drivetrain, RAM 2500/3500 Crew Cab I (facelift 2013) Power Wagon 6.4 Hemi V8 (410 Hp) 4x4 Automatic 2014?
All wheel drive (4x4),
How long is this vehicle, RAM 2500/3500 Crew Cab I (facelift 2013) Power Wagon 6.4 Hemi V8 (410 Hp) 4x4 Automatic 2014?
6027 mm
237.28 in.
How wide is the vehicle, RAM 2500/3500 Crew Cab I (facelift 2013) Power Wagon 6.4 Hemi V8 (410 Hp) 4x4 Automatic 2014?
#N/D
What is the curb weight, RAM 2500/3500 Crew Cab I (facelift 2013) Power Wagon 6.4 Hemi V8 (410 Hp) 4x4 Automatic 2014?
3039 kg
6699.85 lbs.
Ram 2500/3500 (Pick-up) 2500/3500 Crew Cab I (facelift 2013) 2014,2015,2016,2017,2018 Specs
General information
| Brand |
RAM |
| Model |
2500/3500 (Pick-up) |
| Version |
2500/3500 Crew Cab I (facelift 2013) |
| Engine version |
Power Wagon 6.4 Hemi V8 (410 Hp) 4x4 Automatic |
| Year production start |
2014 |
| Year production end |
2018 |
| Vehicle type |
Pick-up |
| Horsepower RPM |
410 Hp @ 5600 rpm. |
| Curb weight kg -lbs total |
3039 kg
6699.85 lbs.
|
| Overall length mm - inch |
6027 mm
237.28 in.
|
| Doors |
4 |
Engine specs
| Cam configuration |
OHV
|
| Engine position and orientation |
Front, Longitudinal |
| Cylinders |
8 |
| Position of cylinders |
V-engine |
| Displacement (liters) |
6417 cm3
391.59 cu. in.
|
| Eng. horsepower RPM |
410 Hp @ 5600 rpm.
|
| Horsepower per litre |
63.9 Hp/l
|
| Weight / horsepower kg/hp - hp/tons |
7.4 kg/Hp
134.9 Hp/tonne
|
| Weight / torque kg/Nm - Nm/tons |
5.2 kg/Nm, 191.5 Nm/tonne
5.2 kg/Nm
191.5 Nm/tonne
|
| Torque Nm RPM lb-ft RPM |
582 Nm @ 4000 rpm.
429.26 lb.-ft. @ 4000 rpm.
|
| Bore (mm in) |
103.9 mm
4.09 in.
|
| Stroke (mm in) |
94.6 mm
3.72 in.
|
| Compression ratio |
10 |
| Fuel delivery system |
Multi-point indirect injection |
| Fuel type |
Petrol (Gasoline) |
| Valvetrain |
2 |
| Engine aspiration |
Naturally aspirated engine |
| Engine oil liters | quarts |
6.6 l
6.97 US qt | 5.81 UK qt
|
| Engine coolant |
15.8 l
16.7 US qt | 13.9 UK qt
|
| Powertrain architecture |
Internal Combustion engine |
| Engine location |
Front, Longitudinal
|
Transmission and Drive system
| Drive configuration |
All wheel drive (4x4)
|
Brakes
| Front brakes |
Disc |
| Rear brakes |
Disc |
| Anti-lock brake system |
ABS (Anti-lock braking system) |
Steering
| Turning diameter m - ft |
14.5 m
47.57 ft.
|
Suspension
| Front suspension |
Multi-link suspension |
| Rear suspension |
Multi-link independent |
Wheels & Tyres
| Wheels size |
275/70 R18 118T; 285/60 R20 115H
|
| Wheels rims |
8J x 18 ET43; 8J x 20 ET55 |
Passenger
| Passengers seats |
44717 |
| Trunk space max liter | cu. Ft. |
1628 l
57.49 cu. ft.
|
Dimensions
| Overall length mm - inch |
6027 mm
237.28 in.
|
| Overall height mm -inch |
2057 mm
80.98 in.
|
| Wheelbase mm - inch |
3792 mm
149.29 in.
|
| Track width front mm - inch |
1742 mm
68.58 in.
|
| Track width rear mm - inch |
1727 mm
67.99 in.
|
Weights
| Curb weight kg -lbs total |
3039 kg
6699.85 lbs.
|
| Gross weight kg -lbs total |
3860 kg
8509.84 lbs.
|
| Capacities kg - lbs |
821 kg
1810 lbs.
|
| Fuel tank liters | gallons |
117 l
30.91 US gal | 25.74 UK gal
|
Engine type
8 CYLINDER V-Engine
