Coupe, 2 Doors, 2 Seats
4.4 l/100 km 53.46 US mpg
64 Hp @ 6500 rpm.
97.4 Hp/l
160 km/h 99.42 mph
657 cm3
40.09 cu. in.
3, Inline
Rear wheel drive,
3295 mm
129.72 in.
1395 mm
54.92 in.
720 kg
1587.33 lbs.
| Brand | Mazda |
|---|---|
| Model | Az-1 (Coupe) |
| Version | Az-1 |
| Engine version | 0.7 (64 Hp) |
| Year production start | 1992 |
| Year production end | 1998 |
| Vehicle type | Coupe |
| Horsepower RPM | 64 Hp @ 6500 rpm. |
| Curb weight kg -lbs total |
720 kg1587.33 lbs. |
| Overall length mm - inch |
3295 mm129.72 in. |
| Doors | 2 |
| Top Speed | 160 km/h 99.42 mph |
| Cam configuration | DOHC |
|---|---|
| Engine position and orientation | Middle, Transverse |
| Cylinders | 3 |
| Position of cylinders | Inline |
| Displacement (liters) |
657 cm340.09 cu. in. |
| Eng. horsepower RPM | 64 Hp @ 6500 rpm. |
| Horsepower per litre | 97.4 Hp/l |
| Weight / horsepower kg/hp - hp/tons |
11.3 kg/Hp88.9 Hp/tonne |
| Weight / torque kg/Nm - Nm/tons | 8.5 kg/Nm, 118.1 Nm/tonne
8.5 kg/Nm118.1 Nm/tonne |
| Torque Nm RPM lb-ft RPM |
85 Nm @ 4000 rpm.62.69 lb.-ft. @ 4000 rpm. |
| Bore (mm in) |
65 mm2.56 in. |
| Stroke (mm in) |
66 mm2.6 in. |
| Compression ratio | 8.3 |
| Fuel delivery system | Multi-point indirect injection |
| Fuel type | Petrol (Gasoline) |
| Valvetrain | 4 |
| Engine aspiration | Turbocharger |
| Powertrain architecture | Internal Combustion engine |
| Engine location | Middle, Transverse |
| Drive configuration | Rear wheel drive |
|---|---|
| Transmission | 5 |
| Front brakes | Disc |
|---|---|
| Rear brakes | Disc |
| Anti-lock brake system | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
|---|
| Front suspension | Wishbone |
|---|---|
| Rear suspension | Helical spring |
| Wheels size | 155/65 R13 |
|---|
| Passengers seats | 2 |
|---|
| Overall length mm - inch |
3295 mm129.72 in. |
|---|---|
| Overall width mm -inch |
1395 mm54.92 in. |
| Overall height mm -inch |
1150 mm45.28 in. |
| Wheelbase mm - inch |
2235 mm87.99 in. |
| Track width front mm - inch |
1200 mm47.24 in. |
| Track width rear mm - inch |
1195 mm47.05 in. |
| Curb weight kg -lbs total |
720 kg1587.33 lbs. |
|---|---|
| Fuel tank liters | gallons |
30 l7.93 US gal | 6.6 UK gal |
| Combined l/100 km - Mpg |
4.4 l/100 km53.46 US mpg |
|---|---|
| Autonomy km (combined use) | 682 |
