MPV, 5 Doors, 7 Seats
163 Hp @ 5500 rpm.
120.8 Hp/l
190 km/h 118.06 mph
1349 cm3
82.32 cu. in.
3, Inline
Front wheel drive,
4684 mm
184.41 in.
1807 mm
71.14 in.
1495 kg
3295.91 lbs.
| Brand | Chevrolet |
|---|---|
| Model | Orlando (MPV) |
| Version | Orlando II |
| Engine version | 530T Ecotec (163 Hp) DSS |
| Year production start | 2018 |
| Vehicle type | MPV |
| Horsepower RPM | 163 Hp @ 5500 rpm. |
| Curb weight kg -lbs total |
1495 kg3295.91 lbs. |
| Overall length mm - inch |
4684 mm184.41 in. |
| Doors | 5 |
| Top Speed | 190 km/h 118.06 mph |
| Engine position and orientation | Front, Transverse |
|---|---|
| Cylinders | 3 |
| Position of cylinders | Inline |
| Displacement (liters) |
1349 cm382.32 cu. in. |
| Eng. horsepower RPM | 163 Hp @ 5500 rpm. |
| Horsepower per litre | 120.8 Hp/l |
| Weight / horsepower kg/hp - hp/tons |
9.2 kg/Hp109 Hp/tonne |
| Weight / torque kg/Nm - Nm/tons | 6.5 kg/Nm, 153.8 Nm/tonne
6.5 kg/Nm153.8 Nm/tonne |
| Torque Nm RPM lb-ft RPM |
230 Nm @ 1800-4400 rpm.169.64 lb.-ft. @ 1800-4400 rpm. |
| Compression ratio | 9.5 |
| Fuel delivery system | Multi-point indirect injection |
| Fuel type | Petrol (Gasoline) |
| Engine aspiration | Turbocharger, Intercooler |
| Powertrain architecture | Internal Combustion engine |
| Engine location | Front, Transverse |
| Drive configuration | Front wheel drive |
|---|
| Front brakes | Ventilated discs |
|---|---|
| Rear brakes | Disc |
| Anti-lock brake system | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
|---|---|
| Turning diameter m - ft |
11.5 m37.73 ft. |
| Front suspension | Independent type McPherson |
|---|---|
| Rear suspension | Independent multi-link suspension |
| Wheels size | 225/50 R17 |
|---|---|
| Wheels rims | 17 |
| Passengers seats | 7 |
|---|---|
| Trunk space min liter | cu. Ft. |
109 l3.85 cu. ft. |
| Trunk space max liter | cu. Ft. |
1520 l53.68 cu. ft. |
| Overall length mm - inch |
4684 mm184.41 in. |
|---|---|
| Overall width mm -inch |
1807 mm71.14 in. |
| Overall height mm -inch |
1627 mm64.06 in. |
| Wheelbase mm - inch |
2796 mm110.08 in. |
| Track width front mm - inch |
1540 mm60.63 in. |
| Track width rear mm - inch |
1540 mm60.63 in. |
| Curb weight kg -lbs total |
1495 kg3295.91 lbs. |
|---|---|
| Fuel tank liters | gallons |
45 l11.89 US gal | 9.9 UK gal |
