Grand Tourer, 5 Doors, 5 Seats
5.8 l/100 km 40.55 US mpg
6.8 l/100 km 34.59 US mpg
5.2 l/100 km 45.23 US mpg
258 Hp @ 4000 rpm.
86.2 Hp/l
246 km/h 152.86 mph
2993 cm3
182.64 cu. in.
6, Inline
Rear wheel drive,
5004 mm
197.01 in.
1901 mm
74.84 in.
1940 kg
4276.97 lbs.
| Brand | BMW |
|---|---|
| Model | 5 Series (Grand Tourer) |
| Version | 5 Series Gran Turismo (F07 LCI, Facelift 2013) |
| Engine version | 530d (258 Hp) Steptronic |
| Year production start | 2013 |
| Year production end | 2017 |
| Vehicle type | Grand Tourer |
| Horsepower RPM | 258 Hp @ 4000 rpm. |
| Acceleration 0 - 100 kmh sec | 6.2 sec |
| Curb weight kg -lbs total |
1940 kg4276.97 lbs. |
| Overall length mm - inch |
5004 mm197.01 in. |
| Doors | 5 |
| Top Speed | 246 km/h 152.86 mph |
| Designation model | N57D30 |
|---|---|
| Engine position and orientation | Front, Longitudinal |
| Cylinders | 6 |
| Position of cylinders | Inline |
| Displacement (liters) |
2993 cm3182.64 cu. in. |
| Eng. horsepower RPM | 258 Hp @ 4000 rpm. |
| Horsepower per litre | 86.2 Hp/l |
| Weight / horsepower kg/hp - hp/tons |
7.5 kg/Hp133 Hp/tonne |
| Weight / torque kg/Nm - Nm/tons | 3.5 kg/Nm, 288.7 Nm/tonne
3.5 kg/Nm288.7 Nm/tonne |
| Torque Nm RPM lb-ft RPM |
560 Nm @ 1500-3000 rpm.413.03 lb.-ft. @ 1500-3000 rpm. |
| Bore (mm in) |
84 mm3.31 in. |
| Stroke (mm in) |
90 mm3.54 in. |
| Compression ratio | 16.5 |
| Fuel delivery system | Diesel Commonrail |
| Fuel type | Diesel |
| Valvetrain | 4 |
| Engine aspiration | Twin-power turbo, Intercooler |
| Engine oil liters | quarts |
6.5 l6.87 US qt | 5.72 UK qt |
| Engine coolant |
10.6 l11.2 US qt | 9.33 UK qt |
| Emission certification | Euro 6 |
| Powertrain architecture | Internal Combustion engine |
| Engine location | Front, Longitudinal |
| Drive configuration | Rear wheel drive |
|---|
| Front brakes | Ventilated discs |
|---|---|
| Rear brakes | Ventilated discs |
| Brake control | Ventilated discs |
| Anti-lock brake system | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
|---|---|
| Turning diameter m - ft |
12.2 m40.03 ft. |
| Front suspension | Double wishbone |
|---|---|
| Rear suspension | Multi-link independent |
| Wheels size | 245/50 R18 100Y RSC |
|---|---|
| Wheels rims | 8J x 18 |
| Passengers seats | 5 |
|---|---|
| Trunk space min liter | cu. Ft. |
500 l17.66 cu. ft. |
| Trunk space max liter | cu. Ft. |
1700 l60.03 cu. ft. |
| Roof load load kg lbs |
75 kg165.35 lbs. |
| Overall length mm - inch |
5004 mm197.01 in. |
|---|---|
| Overall width mm -inch |
1901 mm74.84 in. |
| Overall height mm -inch |
1559 mm61.38 in. |
| Wheelbase mm - inch |
3070 mm120.87 in. |
| Track width front mm - inch |
1611 mm63.43 in. |
| Track width rear mm - inch |
1654 mm65.12 in. |
| Coefficient of drag | 0.29 |
| Curb weight kg -lbs total |
1940 kg4276.97 lbs. |
|---|---|
| Gross weight kg -lbs total |
2570 kg5665.88 lbs. |
| Capacities kg - lbs |
630 kg1388.91 lbs. |
| Fuel tank liters | gallons |
70 l18.49 US gal | 15.4 UK gal |
| City l/100km - mpg |
6.8 l/100 km34.59 US mpg |
|---|---|
| Highway l/100 km - mpg |
5.2 l/100 km45.23 US mpg |
| Combined l/100 km - Mpg |
5.8 l/100 km40.55 US mpg |
| Autonomy km (combined use) | 1207 |
6 CYLINDER INLINE
