Key specs
Mercedes-Benz B-class (MPV) B-class (W245 facelift 2008) 2008,2009,2010
What is the body type, Mercedes-Benz B-class (W245 facelift 2008) B 200 Turbo (193 Hp) Autotronic 2008?
MPV, 5 Doors, 5 Seats
How much power, Mercedes-Benz B-class (W245 facelift 2008) B 200 Turbo (193 Hp) Autotronic 2008?
193 Hp @ 5000 rpm.
94.9 Hp/l
How fast is the car, Mercedes-Benz B-class (W245 facelift 2008) B 200 Turbo (193 Hp) Autotronic 2008?
218 km/h 135.46 mph
What is the engine size, Mercedes-Benz B-class (W245 facelift 2008) B 200 Turbo (193 Hp) Autotronic 2008?
2034 cm3
124.12 cu. in.
How many cylinders, Mercedes-Benz B-class (W245 facelift 2008) B 200 Turbo (193 Hp) Autotronic 2008?
4,
Inline
What is the drivetrain, Mercedes-Benz B-class (W245 facelift 2008) B 200 Turbo (193 Hp) Autotronic 2008?
Front wheel drive,
How long is this vehicle, Mercedes-Benz B-class (W245 facelift 2008) B 200 Turbo (193 Hp) Autotronic 2008?
4273 mm
168.23 in.
How wide is the vehicle, Mercedes-Benz B-class (W245 facelift 2008) B 200 Turbo (193 Hp) Autotronic 2008?
1777 mm
69.96 in.
What is the curb weight, Mercedes-Benz B-class (W245 facelift 2008) B 200 Turbo (193 Hp) Autotronic 2008?
1330 kg
2932.15 lbs.
Mercedes-Benz B-class (MPV) B-class (W245 facelift 2008) 2008,2009,2010 Specs
General information
| Brand |
Mercedes-Benz |
| Model |
B-class (MPV) |
| Version |
B-class (W245 facelift 2008) |
| Engine version |
B 200 Turbo (193 Hp) Autotronic |
| Year production start |
2008 |
| Year production end |
2010 |
| Vehicle type |
MPV |
| Horsepower RPM |
193 Hp @ 5000 rpm. |
| Acceleration 0 - 100 kmh sec |
7.4 sec |
| Curb weight kg -lbs total |
1330 kg
2932.15 lbs.
|
| Overall length mm - inch |
4273 mm
168.23 in.
|
| Doors |
5 |
| Top Speed |
218 km/h 135.46 mph |
Engine specs
| Designation model |
M 266.980 |
| Cam configuration |
SOHC
|
| Engine position and orientation |
Front, Transverse |
| Cylinders |
4 |
| Position of cylinders |
Inline |
| Displacement (liters) |
2034 cm3
124.12 cu. in.
|
| Eng. horsepower RPM |
193 Hp @ 5000 rpm.
|
| Horsepower per litre |
94.9 Hp/l
|
| Weight / horsepower kg/hp - hp/tons |
6.9 kg/Hp
145.1 Hp/tonne
|
| Weight / torque kg/Nm - Nm/tons |
4.8 kg/Nm, 210.5 Nm/tonne
4.8 kg/Nm
210.5 Nm/tonne
|
| Torque Nm RPM lb-ft RPM |
280 Nm @ 1800-4850 rpm.
206.52 lb.-ft. @ 1800-4850 rpm.
|
| Bore (mm in) |
83 mm
3.27 in.
|
| Stroke (mm in) |
94 mm
3.7 in.
|
| Compression ratio |
9 |
| Fuel delivery system |
Multi-point indirect injection |
| Fuel type |
Petrol (Gasoline) |
| Valvetrain |
2 |
| Engine aspiration |
Turbocharger, Intercooler |
| Engine oil liters | quarts |
5 l
5.28 US qt | 4.4 UK qt
|
| Emission certification |
Euro 4
|
| Powertrain architecture |
Internal Combustion engine |
| Engine location |
Front, Transverse
|
Transmission and Drive system
| Drive configuration |
Front wheel drive
|
Brakes
| Front brakes |
Ventilated discs |
| Rear brakes |
Disc |
| Anti-lock brake system |
ABS (Anti-lock braking system) |
Steering
| Steering type |
Steering rack and pinion |
| Turning diameter m - ft |
11.95 m
39.21 ft.
|
Suspension
| Front suspension |
Independent type McPherson, Transverse stabilizer |
| Rear suspension |
Helical spring, Transverse stabilizer |
Wheels & Tyres
| Wheels size |
205/55 R16
|
| Wheels rims |
6J x 16 |
Passenger
| Passengers seats |
5 |
| Trunk space min liter | cu. Ft. |
544 l
19.21 cu. ft.
|
| Trunk space max liter | cu. Ft. |
2245 l
79.28 cu. ft.
|
| Roof load load kg lbs |
75 kg
165.35 lbs.
|
Dimensions
| Overall length mm - inch |
4273 mm
168.23 in.
|
| Overall width mm -inch |
1777 mm
69.96 in.
|
| Overall height mm -inch |
1604 mm
63.15 in.
|
| Wheelbase mm - inch |
2778 mm
109.37 in.
|
| Track width front mm - inch |
1552 mm
61.1 in.
|
| Track width rear mm - inch |
1547 mm
60.91 in.
|
| Coefficient of drag |
0.31
|
Weights
| Curb weight kg -lbs total |
1330 kg
2932.15 lbs.
|
| Gross weight kg -lbs total |
1880 kg
4144.69 lbs.
|
| Capacities kg - lbs |
550 kg
1212.54 lbs.
|
| Fuel tank liters | gallons |
54 l
14.27 US gal | 11.88 UK gal
|
Fuel economy
| Urban (NEDC) l/100 km - Mpg |
10.5-10.7 l/100 km
22.4 - 21.98 US mpg
|
| Extra urban (NEDC) l/100 km - Mpg |
6.7-6.8 l/100 km
35.11 - 34.59 US mpg
|
| Combined (NEDC) l/100 km - Mpg |
8.1-8.2 l/100 km
29.04 - 28.68 US mpg
|
| Autonomy km (combined use) NEDC |
666?6666667 |
Engine type
4 CYLINDER INLINE
