SUV, Crossover, 5 Doors, 5 Seats
340 Hp @ 5000 rpm.
103.6 Hp/l
338 km/h 210.02 mph
3283 cm3
200.34 cu. in.
6, V-engine
All wheel drive (4x4),
5121 mm
201.61 in.
#N/D
2222 kg
4898.67 lbs.
| Brand | Mazda |
|---|---|
| Model | CX-90 (SUV, Crossover) |
| Version | CX-90 |
| Engine version | 3.3 e-SKYACTIV-G (340 Hp) Mild Hybrid i-ACTIV AWD Automatic |
| Year production start | 2023 |
| Vehicle type | SUV, Crossover |
| Horsepower RPM | 340 Hp @ 5000 rpm. |
| Curb weight kg -lbs total |
2222 kg4898.67 lbs. |
| Overall length mm - inch |
5121 mm201.61 in. |
| Doors | 5 |
| Top Speed | 338 km/h 210.02 mph |
| Cam configuration | DOHC, S-VT |
|---|---|
| Engine position and orientation | Front, longitudinal |
| Cylinders | 6 |
| Position of cylinders | V-engine |
| Displacement (liters) |
3283 cm3200.34 cu. in. |
| Eng. horsepower RPM | 340 Hp @ 5000 rpm. |
| Horsepower per litre | 103.6 Hp/l |
| Weight / horsepower kg/hp - hp/tons |
6.5 kg/Hp153 Hp/tonne |
| Weight / torque kg/Nm - Nm/tons | 4.4 kg/Nm, 225 Nm/tonne
4.4 kg/Nm225 Nm/tonne |
| Torque Nm RPM lb-ft RPM |
500 Nm @ 2000 rpm.368.78 lb.-ft. @ 2000 rpm. |
| Bore (mm in) |
86 mm3.39 in. |
| Stroke (mm in) |
94.2 mm3.71 in. |
| Compression ratio | 12 |
| Fuel type | Petrol (Gasoline) |
| Valvetrain | 4 |
| Engine aspiration | Turbocharger, Intercooler |
| Engine oil liters | quarts |
6 l6.34 US qt | 5.28 UK qt |
| Engine coolant |
11.3 l11.94 US qt | 9.94 UK qt |
| Emission certification | ULEV 50 |
| Powertrain architecture | MHEV (Mild Hybrid Electric Vehicle, power-assist hybrid, battery-assisted hybrid vehicles, BAHV) |
| Electric motor power | 17 Hp @ 900 rpm. |
| Electric motor torque | 153 Nm @ 200 rpm. 112.85 lb.-ft. @ 200 rpm. |
| Drive configuration | All wheel drive (4x4) |
|---|
| Front brakes | Ventilated discs, 347.98 mm |
|---|---|
| Rear brakes | Disc, 350.52 mm |
| Anti-lock brake system | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
|---|---|
| Turning diameter m - ft |
11.6 m38.06 ft. |
| Front suspension | Double wishbone |
|---|---|
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Wheels size | 275/45 R21 |
|---|---|
| Wheels rims | 9.5J x 21 |
| Passengers seats | 5 |
|---|---|
| Trunk space min liter | cu. Ft. |
450 l15.89 cu. ft. |
| Trunk space max liter | cu. Ft. |
2129 l75.18 cu. ft. |
| Overall length mm - inch |
5121 mm201.61 in. |
|---|---|
| Overall height mm -inch |
1745 mm68.7 in. |
| Wheelbase mm - inch |
3119 mm122.8 in. |
| Track width front mm - inch |
1704 mm67.09 in. |
| Track width rear mm - inch |
1707 mm67.2 in. |
| Curb weight kg -lbs total |
2222 kg4898.67 lbs. |
|---|---|
| Fuel tank liters | gallons |
74 l19.55 US gal | 16.28 UK gal |
6 CYLINDER V-Engine
