Key specs
Mazda 6 (Hatchback) 6 II Hatchback (GH, facelift 2010) 2010,2011,2012
What is the body type, Mazda 6 II Hatchback (GH, facelift 2010) 2.5 (170 Hp) 2010?
Hatchback, 5 Doors, 5 Seats
How much power, Mazda 6 II Hatchback (GH, facelift 2010) 2.5 (170 Hp) 2010?
170 Hp @ 6000 rpm.
68.3 Hp/l
How fast is the car, Mazda 6 II Hatchback (GH, facelift 2010) 2.5 (170 Hp) 2010?
220 km/h 136.7 mph
What is the engine size, Mazda 6 II Hatchback (GH, facelift 2010) 2.5 (170 Hp) 2010?
2488 cm3
151.83 cu. in.
How many cylinders, Mazda 6 II Hatchback (GH, facelift 2010) 2.5 (170 Hp) 2010?
4,
Inline
What is the drivetrain, Mazda 6 II Hatchback (GH, facelift 2010) 2.5 (170 Hp) 2010?
Front wheel drive,
How long is this vehicle, Mazda 6 II Hatchback (GH, facelift 2010) 2.5 (170 Hp) 2010?
4755 mm
187.2 in.
How wide is the vehicle, Mazda 6 II Hatchback (GH, facelift 2010) 2.5 (170 Hp) 2010?
1795 mm
70.67 in.
What is the curb weight, Mazda 6 II Hatchback (GH, facelift 2010) 2.5 (170 Hp) 2010?
1380 kg
3042.38 lbs.
Mazda 6 (Hatchback) 6 II Hatchback (GH, facelift 2010) 2010,2011,2012 Specs
General information
| Brand |
Mazda |
| Model |
6 (Hatchback) |
| Version |
6 II Hatchback (GH, facelift 2010) |
| Engine version |
2.5 (170 Hp) |
| Year production start |
2010 |
| Year production end |
2012 |
| Vehicle type |
Hatchback |
| Horsepower RPM |
170 Hp @ 6000 rpm. |
| Acceleration 0 - 100 kmh sec |
8.4 sec |
| Curb weight kg -lbs total |
1380 kg
3042.38 lbs.
|
| Overall length mm - inch |
4755 mm
187.2 in.
|
| Doors |
5 |
| Top Speed |
220 km/h 136.7 mph |
Engine specs
| Designation model |
L5-VE |
| Cam configuration |
DOHC
|
| Engine position and orientation |
Front, Transverse |
| Cylinders |
4 |
| Position of cylinders |
Inline |
| Displacement (liters) |
2488 cm3
151.83 cu. in.
|
| Eng. horsepower RPM |
170 Hp @ 6000 rpm.
|
| Horsepower per litre |
68.3 Hp/l
|
| Weight / horsepower kg/hp - hp/tons |
8.1 kg/Hp
123.2 Hp/tonne
|
| Weight / torque kg/Nm - Nm/tons |
6.1 kg/Nm, 163.8 Nm/tonne
6.1 kg/Nm
163.8 Nm/tonne
|
| Torque Nm RPM lb-ft RPM |
226 Nm @ 4000 rpm.
166.69 lb.-ft. @ 4000 rpm.
|
| Bore (mm in) |
89 mm
3.5 in.
|
| Stroke (mm in) |
100 mm
3.94 in.
|
| Compression ratio |
9.7 |
| Fuel delivery system |
Multi-point indirect injection |
| Fuel type |
Petrol (Gasoline) |
| Valvetrain |
4 |
| Engine aspiration |
Naturally aspirated engine |
| Engine oil liters | quarts |
5 l
5.28 US qt | 4.4 UK qt
|
| Engine coolant |
7.5 l
7.93 US qt | 6.6 UK qt
|
| Emission certification |
Euro 5
|
| Powertrain architecture |
Internal Combustion engine |
| Engine location |
Front, Transverse
|
Transmission and Drive system
| Drive configuration |
Front wheel drive
|
| Transmission |
6 |
Brakes
| Front brakes |
Ventilated discs, 299 mm |
| Rear brakes |
Disc, 280 mm |
| Anti-lock brake system |
ABS (Anti-lock braking system) |
Steering
| Steering type |
Steering rack and pinion |
| Turning diameter m - ft |
11.8 m
38.71 ft.
|
Suspension
| Front suspension |
Double wishbone, Transverse stabilizer |
| Rear suspension |
Transverse stabilizer, Independent multi-link |
Wheels & Tyres
| Wheels size |
205/60 R16; 215/50 R17; 225/45 R18
|
| Wheels rims |
6.5J x 16; 7J x 17; 7.5J x 18 |
Passenger
| Passengers seats |
5 |
| Trunk space min liter | cu. Ft. |
510 l
18.01 cu. ft.
|
| Trunk space max liter | cu. Ft. |
1702 l
60.11 cu. ft.
|
| Roof load load kg lbs |
100 kg
220.46 lbs.
|
Dimensions
| Overall length mm - inch |
4755 mm
187.2 in.
|
| Overall width mm -inch |
1795 mm
70.67 in.
|
| Overall height mm -inch |
1440 mm
56.69 in.
|
| Wheelbase mm - inch |
2725 mm
107.28 in.
|
| Track width front mm - inch |
1550-1570 mm
61.02 - 61.81 in.
|
| Track width rear mm - inch |
1550-1570 mm
61.02 - 61.81 in.
|
Weights
| Curb weight kg -lbs total |
1380 kg
3042.38 lbs.
|
| Gross weight kg -lbs total |
1970 kg
4343.11 lbs.
|
| Capacities kg - lbs |
590 kg
1300.73 lbs.
|
| Fuel tank liters | gallons |
64 l
16.91 US gal | 14.08 UK gal
|
Fuel economy
| Urban (NEDC) l/100 km - Mpg |
11.1 l/100 km
21.19 US mpg
|
| Extra urban (NEDC) l/100 km - Mpg |
6.3 l/100 km
37.34 US mpg
|
| Combined (NEDC) l/100 km - Mpg |
8 l/100 km
29.4 US mpg
|
| Autonomy km (combined use) NEDC |
#VALORE! |
Engine type
4 CYLINDER INLINE
