Minivan, MPV, 5 Doors, 6 Seats
275 Hp @ 6000 rpm.
114.9 Hp/l
185 km/h 114.95 mph
2393 cm3
146.03 cu. in.
4, Inline
All wheel drive (4x4),
5125 mm
201.77 in.
1890 mm
74.41 in.
#N/D
| Brand | Lexus |
|---|---|
| Model | LM (Minivan, MPV) |
| Version | LM II |
| Engine version | 500h (371 Hp) Hybrid DIRECT4 Direct Shift 6 Seat |
| Year production start | 2023 |
| Vehicle type | Minivan, MPV |
| Horsepower RPM | 275 Hp @ 6000 rpm. |
| Acceleration 0 - 100 kmh sec | 6.9 sec |
| Overall length mm - inch |
5125 mm201.77 in. |
| Doors | 5 |
| Top Speed | 185 km/h 114.95 mph |
| Designation model | T24A-FTS |
|---|---|
| Cam configuration | Dual VVT-i |
| Cylinders | 4 |
| Position of cylinders | Inline |
| Displacement (liters) |
2393 cm3146.03 cu. in. |
| Eng. horsepower RPM | 275 Hp @ 6000 rpm. |
| Horsepower per litre | 114.9 Hp/l |
| Torque Nm RPM lb-ft RPM |
460 Nm @ 2000-3000 rpm.339.28 lb.-ft. @ 2000-3000 rpm. |
| Bore (mm in) |
87.5 mm3.44 in. |
| Stroke (mm in) |
99.5 mm3.92 in. |
| Compression ratio | 11 |
| Fuel type | Petrol (Gasoline) |
| Valvetrain | 4 |
| Engine aspiration | Twin-scroll turbo, Intercooler |
| Engine oil liters | quarts |
5.3 l5.6 US qt | 4.66 UK qt |
| Engine coolant |
11.2 l11.83 US qt | 9.85 UK qt |
| Powertrain architecture | FHEV (Full Hybrid Electric Vehicle) |
| Electric motor power | 87 Hp |
| Electric motor torque | 292 Nm 215.37 lb.-ft. |
| Total available power | 371 Hp |
| Drive configuration | All wheel drive (4x4) |
|---|
| Front brakes | Ventilated discs, 328 mm |
|---|---|
| Rear brakes | Ventilated discs, 317 mm |
| Anti-lock brake system | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
|---|---|
| Turning diameter m - ft |
11.8 m38.71 ft. |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
|---|---|
| Rear suspension | Double wishbone, Independent coil spring, Transverse stabilizer |
| Wheels size | 225/65 R17; 225/55 R19 |
|---|---|
| Wheels rims | 6.5J x 17; 7J x 19 |
| Passengers seats | 6 |
|---|---|
| Trunk space min liter | cu. Ft. |
110 l3.88 cu. ft. |
| Trunk space max liter | cu. Ft. |
1190 l42.02 cu. ft. |
| Overall length mm - inch |
5125 mm201.77 in. |
|---|---|
| Overall width mm -inch |
1890 mm74.41 in. |
| Overall height mm -inch |
1955 mm76.97 in. |
| Wheelbase mm - inch |
3000 mm118.11 in. |
| Track width front mm - inch |
1615 mm63.58 in. |
| Track width rear mm - inch |
1620 mm63.78 in. |
| Coefficient of drag | 0.33 |
| Fuel tank liters | gallons |
60 l15.85 US gal | 13.2 UK gal |
|---|
