Coupe, 2 Doors, 2 Seats
19.6 l/100 km 12 US mpg
21.4 l/100 km 10.99 US mpg
14.7 l/100 km 16 US mpg
560 Hp @ 8700 rpm.
116.5 Hp/l
325 km/h 201.95 mph
4805 cm3
293.22 cu. in.
10, V-engine
Rear wheel drive,
4505 mm
177.36 in.
1895 mm
74.61 in.
1480-1590 kg
3262.84 - 3505.35 lbs.
| Brand | Lexus |
|---|---|
| Model | LFA (Coupe) |
| Version | LFA |
| Engine version | 4.8 V10 (560 Hp) Automatic |
| Year production start | 2010 |
| Year production end | 2012 |
| Vehicle type | Coupe |
| Horsepower RPM | 560 Hp @ 8700 rpm. |
| Acceleration 0 - 100 kmh sec | 3.7 sec |
| Curb weight kg -lbs total |
1480-1590 kg3262.84 - 3505.35 lbs. |
| Overall length mm - inch |
4505 mm177.36 in. |
| Doors | 2 |
| Top Speed | 325 km/h 201.95 mph |
| Designation model | 1LR-GUE |
|---|---|
| Cam configuration | DOHC, VVTi |
| Engine position and orientation | Front, Longitudinal |
| Cylinders | 10 |
| Position of cylinders | V-engine |
| Displacement (liters) |
4805 cm3293.22 cu. in. |
| Eng. horsepower RPM | 560 Hp @ 8700 rpm. |
| Horsepower per litre | 116.5 Hp/l |
| Weight / horsepower kg/hp - hp/tons |
2.6 kg/Hp378.4 Hp/tonne |
| Weight / torque kg/Nm - Nm/tons | 3.1 kg/Nm, 324.3 Nm/tonne
3.1 kg/Nm324.3 Nm/tonne |
| Torque Nm RPM lb-ft RPM |
480 Nm @ 7000 rpm.354.03 lb.-ft. @ 7000 rpm. |
| Bore (mm in) |
88 mm3.46 in. |
| Stroke (mm in) |
79 mm3.11 in. |
| Compression ratio | 12 |
| Fuel delivery system | Direct injection |
| Fuel type | Petrol (Gasoline) |
| Valvetrain | 4 |
| Engine aspiration | Naturally aspirated engine |
| Engine oil liters | quarts |
13.5 l14.27 US qt | 11.88 UK qt |
| Engine coolant |
25.5 l26.95 US qt | 22.44 UK qt |
| Emission certification | Euro 5 |
| Powertrain architecture | Internal Combustion engine |
| Engine location | Front, Longitudinal |
| Drive configuration | Rear wheel drive |
|---|
| Front brakes | Ventilated discs, 390 mm |
|---|---|
| Rear brakes | Ventilated discs, 360 mm |
| Anti-lock brake system | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
|---|---|
| Turning diameter m - ft |
12.2 m40.03 ft. |
| Front suspension | Double wishbone |
|---|---|
| Rear suspension | Multi-link independent |
| Wheels size | Front wheel tires: 265/35 ZR20 |
|---|---|
| Wheels rims | Front wheel rims: 9.5J x 20 |
| Passengers seats | 2 |
|---|
| Overall length mm - inch |
4505 mm177.36 in. |
|---|---|
| Overall width mm -inch |
1895 mm74.61 in. |
| Overall height mm -inch |
1265 mm49.8 in. |
| Wheelbase mm - inch |
2605 mm102.56 in. |
| Track width front mm - inch |
1580 mm62.2 in. |
| Track width rear mm - inch |
1570 mm61.81 in. |
| Coefficient of drag | 0.31 |
| Curb weight kg -lbs total |
1480-1590 kg3262.84 - 3505.35 lbs. |
|---|---|
| Gross weight kg -lbs total |
1755 kg3869.11 lbs. |
| Capacities kg - lbs |
165-275 kg363.76 - 606.27 lbs. |
| Fuel tank liters | gallons |
73 l19.28 US gal | 16.06 UK gal |
| City l/100km - mpg |
21.4 l/100 km10.99 US mpg |
|---|---|
| Highway l/100 km - mpg |
14.7 l/100 km16 US mpg |
| Combined l/100 km - Mpg |
19.6 l/100 km12 US mpg |
| Autonomy km (combined use) | 384 |
10 CYLINDER V-Engine
