Minivan, 5 Doors, 44780 Seats
11.8 l/100 km 19.93 US mpg
13.1 l/100 km 17.96 US mpg
9.8 l/100 km 24 US mpg
280 Hp @ 6000 rpm.
83.8 Hp/l
217 km/h 134.84 mph
3342 cm3
203.94 cu. in.
6, V-engine
Front wheel drive,
5116 mm
201.42 in.
1984 mm
78.11 in.
2001-2059 kg
4411.45 - 4539.32 lbs.
| Brand | Kia |
|---|---|
| Model | Sedona (Minivan) |
| Version | Sedona III |
| Engine version | 3.3 V6 (280 Hp) Automatic |
| Year production start | 2015 |
| Vehicle type | Minivan |
| Horsepower RPM | 280 Hp @ 6000 rpm. |
| Acceleration 0 - 100 kmh sec | 8.2 sec |
| Curb weight kg -lbs total |
2001-2059 kg4411.45 - 4539.32 lbs. |
| Overall length mm - inch |
5116 mm201.42 in. |
| Doors | 5 |
| Top Speed | 217 km/h 134.84 mph |
| Cam configuration | DOHC-CVVT |
|---|---|
| Engine position and orientation | Front, Transverse |
| Cylinders | 6 |
| Position of cylinders | V-engine |
| Displacement (liters) |
3342 cm3203.94 cu. in. |
| Eng. horsepower RPM | 280 Hp @ 6000 rpm. |
| Horsepower per litre | 83.8 Hp/l |
| Weight / horsepower kg/hp - hp/tons |
7.1 kg/Hp139.9 Hp/tonne |
| Weight / torque kg/Nm - Nm/tons | 6 kg/Nm, 167.9 Nm/tonne
6 kg/Nm167.9 Nm/tonne |
| Torque Nm RPM lb-ft RPM |
336 Nm @ 5200 rpm.247.82 lb.-ft. @ 5200 rpm. |
| Bore (mm in) |
92 mm3.62 in. |
| Stroke (mm in) |
83.8 mm3.3 in. |
| Compression ratio | 11.5 |
| Fuel delivery system | Direct injection |
| Fuel type | Petrol (Gasoline) |
| Valvetrain | 4 |
| Engine aspiration | Naturally aspirated engine |
| Powertrain architecture | Internal Combustion engine |
| Engine location | Front, Transverse |
| Drive configuration | Front wheel drive |
|---|
| Front brakes | Ventilated discs |
|---|---|
| Rear brakes | Disc |
| Anti-lock brake system | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
|---|---|
| Turning diameter m - ft |
11.21 m36.78 ft. |
| Front suspension | Independent, Spring McPherson, with stabilizer |
|---|---|
| Rear suspension | Independent, spring multi-link with stabilizer |
| Wheels size | 195/65 R15; 205/55 R16; 235/65 R17; 235/60 R18 |
|---|---|
| Wheels rims | 6.0J x 15; 6.5J x 16; 6.5J x 17; 6.5J x 18 |
| Passengers seats | 44780 |
|---|---|
| Trunk space min liter | cu. Ft. |
2220 l78.4 cu. ft. |
| Trunk space max liter | cu. Ft. |
4021 l142 cu. ft. |
| Overall length mm - inch |
5116 mm201.42 in. |
|---|---|
| Overall width mm -inch |
1984 mm78.11 in. |
| Overall height mm -inch |
1740 mm68.5 in. |
| Wheelbase mm - inch |
3061 mm120.51 in. |
| Track width front mm - inch |
1740 mm68.5 in. |
| Track width rear mm - inch |
1747 mm68.78 in. |
| Coefficient of drag | 0.33 |
| Curb weight kg -lbs total |
2001-2059 kg4411.45 - 4539.32 lbs. |
|---|---|
| Gross weight kg -lbs total |
2760 kg6084.76 lbs. |
| Capacities kg - lbs |
701-759 kg1545.44 - 1673.31 lbs. |
| Fuel tank liters | gallons |
80 l21.13 US gal | 17.6 UK gal |
| City l/100km - mpg |
13.1 l/100 km17.96 US mpg |
|---|---|
| Highway l/100 km - mpg |
9.8 l/100 km24 US mpg |
| Combined l/100 km - Mpg |
11.8 l/100 km19.93 US mpg |
| Autonomy km (combined use) | 727 |
