Hatchback, 5 Doors, 5 Seats
84 Hp @ 6000 rpm.
70.2 Hp/l
173 km/h 107.5 mph
1197 cm3
73.05 cu. in.
4, Inline
Front wheel drive,
4065 mm
160.04 in.
1725 mm
67.91 in.
1045-1143 kg
2303.83 - 2519.88 lbs.
| Brand | Kia |
|---|---|
| Model | Rio (Hatchback) |
| Version | Rio IV Hatchback (YB, facelift 2020) |
| Engine version | 1.2i (84 Hp) |
| Year production start | 2020 |
| Vehicle type | Hatchback |
| Horsepower RPM | 84 Hp @ 6000 rpm. |
| Acceleration 0 - 100 kmh sec | 13.1 sec |
| Curb weight kg -lbs total |
1045-1143 kg2303.83 - 2519.88 lbs. |
| Overall length mm - inch |
4065 mm160.04 in. |
| Doors | 5 |
| Top Speed | 173 km/h 107.5 mph |
| Designation model | G4LF |
|---|---|
| Engine position and orientation | Front, Transverse |
| Cylinders | 4 |
| Position of cylinders | Inline |
| Displacement (liters) |
1197 cm373.05 cu. in. |
| Eng. horsepower RPM | 84 Hp @ 6000 rpm. |
| Horsepower per litre | 70.2 Hp/l |
| Weight / horsepower kg/hp - hp/tons |
12.4 kg/Hp80.4 Hp/tonne |
| Weight / torque kg/Nm - Nm/tons | 8.9 kg/Nm, 112.9 Nm/tonne
8.9 kg/Nm112.9 Nm/tonne |
| Torque Nm RPM lb-ft RPM |
118 Nm @ 4000 rpm.87.03 lb.-ft. @ 4000 rpm. |
| Bore (mm in) |
71 mm2.8 in. |
| Stroke (mm in) |
75.6 mm2.98 in. |
| Compression ratio | 11 |
| Fuel delivery system | Multi-point indirect injection |
| Fuel type | Petrol (Gasoline) |
| Valvetrain | 4 |
| Engine aspiration | Naturally aspirated engine |
| Emission certification | Euro 6d-ISC-FCM |
| Powertrain architecture | Internal Combustion engine |
| Engine location | Front, Transverse |
| Drive configuration | Front wheel drive |
|---|---|
| Transmission | 5 |
| Front brakes | Ventilated discs, 256 mm |
|---|---|
| Rear brakes | Drum, 203 mm |
| Anti-lock brake system | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
|---|---|
| Turning diameter m - ft |
10.2 m33.46 ft. |
| Front suspension | Independent, Spring McPherson, with stabilizer |
|---|---|
| Rear suspension | Helical spring, Elastic beam |
| Wheels size | 185/65 R15 88H; 195/55 R16 87H |
|---|---|
| Wheels rims | 6.0J x 15; 6.0J x 16 |
| Passengers seats | 5 |
|---|---|
| Trunk space min liter | cu. Ft. |
325 l11.48 cu. ft. |
| Trunk space max liter | cu. Ft. |
1103 l38.95 cu. ft. |
| Roof load load kg lbs |
70 kg154.32 lbs. |
| Overall length mm - inch |
4065 mm160.04 in. |
|---|---|
| Overall width mm -inch |
1725 mm67.91 in. |
| Overall height mm -inch |
1450 mm57.09 in. |
| Wheelbase mm - inch |
2580 mm101.57 in. |
| Track width front mm - inch |
1512-1518 mm59.53 - 59.76 in. |
| Track width rear mm - inch |
1518-1524 mm59.76 - 60 in. |
| Curb weight kg -lbs total |
1045-1143 kg2303.83 - 2519.88 lbs. |
|---|---|
| Gross weight kg -lbs total |
1570 kg3461.26 lbs. |
| Capacities kg - lbs |
427-525 kg941.37 - 1157.43 lbs. |
| Fuel tank liters | gallons |
45 l11.89 US gal | 9.9 UK gal |
