Key specs
Hyundai Nexo (SUV) Nexo 2018,2019,2020,2021,2022,2023,2024,2025
What is the body type, Hyundai Nexo 1.56 kWh (184 Hp) Fuel Cell CVT 2018?
SUV, 5 Doors, 5 Seats
How fast is the car, Hyundai Nexo 1.56 kWh (184 Hp) Fuel Cell CVT 2018?
177 km/h 109.98 mph
How many cylinders, Hyundai Nexo 1.56 kWh (184 Hp) Fuel Cell CVT 2018?
Electric,
What is the drivetrain, Hyundai Nexo 1.56 kWh (184 Hp) Fuel Cell CVT 2018?
Front wheel drive,
How long is this vehicle, Hyundai Nexo 1.56 kWh (184 Hp) Fuel Cell CVT 2018?
4670 mm
183.86 in.
How wide is the vehicle, Hyundai Nexo 1.56 kWh (184 Hp) Fuel Cell CVT 2018?
1860 mm
73.23 in.
What is the curb weight, Hyundai Nexo 1.56 kWh (184 Hp) Fuel Cell CVT 2018?
1889 kg
4164.53 lbs.
Hyundai Nexo (SUV) Nexo 2018,2019,2020,2021,2022,2023,2024,2025 Specs
General information
| Brand |
Hyundai |
| Model |
Nexo (SUV) |
| Version |
Nexo |
| Engine version |
1.56 kWh (184 Hp) Fuel Cell CVT |
| Year production start |
2018 |
| Vehicle type |
SUV |
| Acceleration 0 - 100 kmh sec |
9.2 sec |
| Curb weight kg -lbs total |
1889 kg
4164.53 lbs.
|
| Overall length mm - inch |
4670 mm
183.86 in.
|
| Doors |
5 |
| Top Speed |
177 km/h 109.98 mph |
Engine specs
| Cylinders |
Electric |
| Weight / horsepower kg/hp - hp/tons |
10.3 kg/Hp
97.4 Hp/tonne
|
| Fuel type |
Hydrogen / electricity |
| Powertrain architecture |
FCEV (Fuel Cell Electric Vehicle) |
| Electric motor power |
163 Hp
|
| Electric motor torque |
395 Nm 291.34 lb.-ft.
|
| Total available power |
184 Hp
|
Transmission and Drive system
| Drive configuration |
Front wheel drive
|
Brakes
| Front brakes |
Ventilated discs |
| Rear brakes |
Disc |
| Anti-lock brake system |
ABS (Anti-lock braking system) |
Steering
| Steering type |
Steering rack and pinion |
| Turning diameter m - ft |
11.2 m
36.75 ft.
|
Suspension
| Front suspension |
Independent, Spring McPherson, with stabilizer |
| Rear suspension |
Independent, spring multi-link with stabilizer |
Wheels & Tyres
| Wheels size |
225/60 R17; 245/45 R19
|
| Wheels rims |
7.0J x 17; 7.5J x 19 |
Passenger
| Passengers seats |
5 |
| Trunk space min liter | cu. Ft. |
461 l
16.28 cu. ft.
|
| Trunk space max liter | cu. Ft. |
1466 l
51.77 cu. ft.
|
| Roof load load kg lbs |
100 kg
220.46 lbs.
|
Dimensions
| Overall length mm - inch |
4670 mm
183.86 in.
|
| Overall width mm -inch |
1860 mm
73.23 in.
|
| Overall height mm -inch |
1630-1640 mm
64.17 - 64.57 in.
|
| Wheelbase mm - inch |
2790 mm
109.84 in.
|
| Track width front mm - inch |
1614/1618 mm
63.54 in.
|
| Track width rear mm - inch |
1625/1629 mm
63.98 in.
|
| Coefficient of drag |
0.32
|
Weights
| Curb weight kg -lbs total |
1889 kg
4164.53 lbs.
|
| Gross weight kg -lbs total |
2340 kg
5158.82 lbs.
|
| Capacities kg - lbs |
451 kg
994.28 lbs.
|
Engine type
Electric
