Coupe, 3 Doors, 5 Seats
7.3 l/100 km 32.22 US mpg
9.6 l/100 km 24.5 US mpg
6 l/100 km 39.2 US mpg
186 Hp @ 5500 rpm.
116.9 Hp/l
219 km/h 136.08 mph
1591 cm3
97.09 cu. in.
4, Inline
Front wheel drive,
4300 mm
169.29 in.
1780 mm
70.08 in.
1282-1380 kg
2826.33 - 3042.38 lbs.
| Brand | Hyundai |
|---|---|
| Model | i30 (Coupe) |
| Version | i30 II Coupe (facelift 2015) |
| Engine version | 1.6 T-GDi (186 Hp) |
| Year production start | 2015 |
| Year production end | 2017 |
| Vehicle type | Coupe |
| Horsepower RPM | 186 Hp @ 5500 rpm. |
| Acceleration 0 - 100 kmh sec | 8 sec |
| Curb weight kg -lbs total |
1282-1380 kg2826.33 - 3042.38 lbs. |
| Overall length mm - inch |
4300 mm169.29 in. |
| Doors | 3 |
| Top Speed | 219 km/h 136.08 mph |
| Cam configuration | DOHC |
|---|---|
| Engine position and orientation | Front, Transverse |
| Cylinders | 4 |
| Position of cylinders | Inline |
| Displacement (liters) |
1591 cm397.09 cu. in. |
| Eng. horsepower RPM | 186 Hp @ 5500 rpm. |
| Horsepower per litre | 116.9 Hp/l |
| Weight / horsepower kg/hp - hp/tons |
6.9 kg/Hp145.1 Hp/tonne |
| Weight / torque kg/Nm - Nm/tons | 4.8 kg/Nm, 206.7 Nm/tonne
4.8 kg/Nm206.7 Nm/tonne |
| Torque Nm RPM lb-ft RPM |
265 Nm @ 1500-4500 rpm.195.45 lb.-ft. @ 1500-4500 rpm. |
| Bore (mm in) |
77 mm3.03 in. |
| Stroke (mm in) |
85.44 mm3.36 in. |
| Compression ratio | 9.5 |
| Fuel delivery system | Direct injection |
| Fuel type | Petrol (Gasoline) |
| Valvetrain | 4 |
| Engine aspiration | Turbocharger |
| Emission certification | Euro 6 |
| Powertrain architecture | Internal Combustion engine |
| Engine location | Front, Transverse |
| Drive configuration | Front wheel drive |
|---|---|
| Transmission | 6 |
| Front brakes | Ventilated discs |
|---|---|
| Rear brakes | Disc |
| Anti-lock brake system | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
|---|---|
| Turning diameter m - ft |
10.6 m34.78 ft. |
| Front suspension | Independent, Spring McPherson, with stabilizer |
|---|---|
| Rear suspension | Multi-link independent |
| Wheels size | 225/40 R18 |
|---|---|
| Wheels rims | 7.5J x 18 |
| Passengers seats | 5 |
|---|---|
| Trunk space min liter | cu. Ft. |
378 l13.35 cu. ft. |
| Trunk space max liter | cu. Ft. |
1316 l46.47 cu. ft. |
| Roof load load kg lbs |
80 kg176.37 lbs. |
| Overall length mm - inch |
4300 mm169.29 in. |
|---|---|
| Overall width mm -inch |
1780 mm70.08 in. |
| Overall height mm -inch |
1470 mm57.87 in. |
| Wheelbase mm - inch |
2650 mm104.33 in. |
| Track width front mm - inch |
1553 mm61.14 in. |
| Track width rear mm - inch |
1545 mm60.83 in. |
| Curb weight kg -lbs total |
1282-1380 kg2826.33 - 3042.38 lbs. |
|---|---|
| Gross weight kg -lbs total |
1870 kg4122.64 lbs. |
| Capacities kg - lbs |
490-588 kg1080.27 - 1296.32 lbs. |
| Fuel tank liters | gallons |
53 l14 US gal | 11.66 UK gal |
| City l/100km - mpg |
9.6 l/100 km24.5 US mpg |
|---|---|
| Highway l/100 km - mpg |
6 l/100 km39.2 US mpg |
| Combined l/100 km - Mpg |
7.3 l/100 km32.22 US mpg |
| Autonomy km (combined use) | 726 |
