Minivan, 4 Doors, 4 Seats
8.62 l/100 km 27.29 US mpg
5.35 l/100 km 43.97 US mpg
140 Hp @ 5500 rpm.
71 Hp/l
160 km/h 99.42 mph
1973 cm3
120.4 cu. in.
4, Inline
Front wheel drive,
3935 mm
154.92 in.
1695 mm
66.73 in.
1370 kg
3020.33 lbs.
| Brand | Honda |
|---|---|
| Model | S-MX (Minivan) |
| Version | S-MX |
| Engine version | 2.0 i 16V (140 Hp) |
| Year production start | 1996 |
| Year production end | 2002 |
| Vehicle type | Minivan |
| Horsepower RPM | 140 Hp @ 5500 rpm. |
| Curb weight kg -lbs total |
1370 kg3020.33 lbs. |
| Overall length mm - inch |
3935 mm154.92 in. |
| Doors | 4 |
| Top Speed | 160 km/h 99.42 mph |
| Cam configuration | DOHC |
|---|---|
| Engine position and orientation | Front, Transverse |
| Cylinders | 4 |
| Position of cylinders | Inline |
| Displacement (liters) |
1973 cm3120.4 cu. in. |
| Eng. horsepower RPM | 140 Hp @ 5500 rpm. |
| Horsepower per litre | 71 Hp/l |
| Weight / horsepower kg/hp - hp/tons |
9.8 kg/Hp102.2 Hp/tonne |
| Weight / torque kg/Nm - Nm/tons | 7.4 kg/Nm, 135.8 Nm/tonne
7.4 kg/Nm135.8 Nm/tonne |
| Torque Nm RPM lb-ft RPM |
186 Nm @ 4200 rpm.137.19 lb.-ft. @ 4200 rpm. |
| Bore (mm in) |
84 mm3.31 in. |
| Stroke (mm in) |
89 mm3.5 in. |
| Compression ratio | 9.6 |
| Fuel delivery system | Multi-point indirect injection |
| Fuel type | Petrol (Gasoline) |
| Valvetrain | 4 |
| Engine aspiration | Naturally aspirated engine |
| Powertrain architecture | Internal Combustion engine |
| Engine location | Front, Transverse |
| Drive configuration | Front wheel drive |
|---|
| Front brakes | Disc |
|---|---|
| Rear brakes | Drum |
| Anti-lock brake system | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
|---|
| Front suspension | Spring Strut |
|---|---|
| Rear suspension | Double wishbone |
| Wheels size | 195/65 R15 |
|---|---|
| Wheels rims | 15 |
| Passengers seats | 4 |
|---|---|
| Trunk space min liter | cu. Ft. |
340 l12.01 cu. ft. |
| Trunk space max liter | cu. Ft. |
920 l32.49 cu. ft. |
| Overall length mm - inch |
3935 mm154.92 in. |
|---|---|
| Overall width mm -inch |
1695 mm66.73 in. |
| Overall height mm -inch |
1735 mm68.31 in. |
| Wheelbase mm - inch |
2500 mm98.43 in. |
| Track width front mm - inch |
1490 mm58.66 in. |
| Track width rear mm - inch |
1490 mm58.66 in. |
| Curb weight kg -lbs total |
1370 kg3020.33 lbs. |
|---|---|
| Gross weight kg -lbs total |
1645 kg3626.6 lbs. |
| Capacities kg - lbs |
275 kg606.27 lbs. |
| Fuel tank liters | gallons |
65 l17.17 US gal | 14.3 UK gal |
| City l/100km - mpg |
8.62 l/100 km27.29 US mpg |
|---|---|
| Highway l/100 km - mpg |
5.35 l/100 km43.97 US mpg |
