Coupe, 2 Doors, 5 Seats
10.8 l/100 km 21.78 US mpg
205 Hp @ 5500 rpm.
63.9 Hp/l
226 km/h 140.43 mph
3206 cm3
195.64 cu. in.
6, V-engine
Front wheel drive,
4885 mm
192.32 in.
1810 mm
71.26 in.
1545 kg
3406.14 lbs.
| Brand | Honda |
|---|---|
| Model | Legend (Coupe) |
| Version | Legend II Coupe (KA8) |
| Engine version | 3.2i 24V (205 Hp) |
| Year production start | 1991 |
| Year production end | 1996 |
| Vehicle type | Coupe |
| Horsepower RPM | 205 Hp @ 5500 rpm. |
| Acceleration 0 - 100 kmh sec | 7.3 sec |
| Curb weight kg -lbs total |
1545 kg3406.14 lbs. |
| Overall length mm - inch |
4885 mm192.32 in. |
| Doors | 2 |
| Top Speed | 226 km/h 140.43 mph |
| Cam configuration | OHC |
|---|---|
| Engine position and orientation | Front, Longitudinal |
| Cylinders | 6 |
| Position of cylinders | V-engine |
| Displacement (liters) |
3206 cm3195.64 cu. in. |
| Eng. horsepower RPM | 205 Hp @ 5500 rpm. |
| Horsepower per litre | 63.9 Hp/l |
| Weight / horsepower kg/hp - hp/tons |
7.5 kg/Hp132.7 Hp/tonne |
| Weight / torque kg/Nm - Nm/tons | 5.3 kg/Nm, 189.6 Nm/tonne
5.3 kg/Nm189.6 Nm/tonne |
| Torque Nm RPM lb-ft RPM |
293 Nm @ 4400 rpm.216.11 lb.-ft. @ 4400 rpm. |
| Bore (mm in) |
90 mm3.54 in. |
| Stroke (mm in) |
84 mm3.31 in. |
| Compression ratio | 9.6 |
| Fuel delivery system | Multi-point indirect injection |
| Fuel type | Petrol (Gasoline) |
| Valvetrain | 4 |
| Engine aspiration | Naturally aspirated engine |
| Powertrain architecture | Internal Combustion engine |
| Engine location | Front, Longitudinal |
| Drive configuration | Front wheel drive |
|---|---|
| Transmission | 5 |
| Front brakes | Ventilated discs |
|---|---|
| Rear brakes | Disc |
| Anti-lock brake system | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
|---|
| Front suspension | Double wishbone |
|---|---|
| Rear suspension | Double wishbone |
| Wheels size | 205/65 R15 |
|---|
| Passengers seats | 5 |
|---|---|
| Trunk space min liter | cu. Ft. |
417 l14.73 cu. ft. |
| Overall length mm - inch |
4885 mm192.32 in. |
|---|---|
| Overall width mm -inch |
1810 mm71.26 in. |
| Overall height mm -inch |
1370 mm53.94 in. |
| Wheelbase mm - inch |
2830 mm111.42 in. |
| Track width front mm - inch |
1550 mm61.02 in. |
| Track width rear mm - inch |
1540 mm60.63 in. |
| Curb weight kg -lbs total |
1545 kg3406.14 lbs. |
|---|---|
| Gross weight kg -lbs total |
2150 kg4739.94 lbs. |
| Capacities kg - lbs |
605 kg1333.8 lbs. |
| Fuel tank liters | gallons |
68 l17.96 US gal | 14.96 UK gal |
| Combined l/100 km - Mpg |
10.8 l/100 km21.78 US mpg |
|---|---|
| Autonomy km (combined use) | 680 |
