Key specs
Ford Explorer (SUV) Explorer VI 2019,2020,2021,2022,2023,2024
What is the body type, Ford Explorer VI ST 3.0 V6 (400 Hp) AWD Automatic 2019?
SUV, 5 Doors, 6 Seats
How much power, Ford Explorer VI ST 3.0 V6 (400 Hp) AWD Automatic 2019?
400 Hp @ 5500 rpm.
135.3 Hp/l
What is the engine size, Ford Explorer VI ST 3.0 V6 (400 Hp) AWD Automatic 2019?
2956 cm3
180.39 cu. in.
How many cylinders, Ford Explorer VI ST 3.0 V6 (400 Hp) AWD Automatic 2019?
6,
V-engine
What is the drivetrain, Ford Explorer VI ST 3.0 V6 (400 Hp) AWD Automatic 2019?
All wheel drive (4x4),
How long is this vehicle, Ford Explorer VI ST 3.0 V6 (400 Hp) AWD Automatic 2019?
5062 mm
199.29 in.
How wide is the vehicle, Ford Explorer VI ST 3.0 V6 (400 Hp) AWD Automatic 2019?
2004 mm
78.9 in.
What is the curb weight, Ford Explorer VI ST 3.0 V6 (400 Hp) AWD Automatic 2019?
2115 kg
4662.78 lbs.
Ford Explorer (SUV) Explorer VI 2019,2020,2021,2022,2023,2024 Specs
General information
| Brand |
Ford |
| Model |
Explorer (SUV) |
| Version |
Explorer VI |
| Engine version |
ST 3.0 V6 (400 Hp) AWD Automatic |
| Year production start |
2019 |
| Vehicle type |
SUV |
| Horsepower RPM |
400 Hp @ 5500 rpm. |
| Curb weight kg -lbs total |
2115 kg
4662.78 lbs.
|
| Overall length mm - inch |
5062 mm
199.29 in.
|
| Doors |
5 |
Engine specs
| Cam configuration |
DOHC
|
| Engine position and orientation |
Front, Longitudinal |
| Cylinders |
6 |
| Position of cylinders |
V-engine |
| Displacement (liters) |
2956 cm3
180.39 cu. in.
|
| Eng. horsepower RPM |
400 Hp @ 5500 rpm.
|
| Horsepower per litre |
135.3 Hp/l
|
| Weight / horsepower kg/hp - hp/tons |
5.3 kg/Hp
189.1 Hp/tonne
|
| Weight / torque kg/Nm - Nm/tons |
3.8 kg/Nm, 266.2 Nm/tonne
3.8 kg/Nm
266.2 Nm/tonne
|
| Torque Nm RPM lb-ft RPM |
563 Nm @ 3500 rpm.
415.25 lb.-ft. @ 3500 rpm.
|
| Bore (mm in) |
85.4 mm
3.36 in.
|
| Stroke (mm in) |
86 mm
3.39 in.
|
| Compression ratio |
9.5 |
| Fuel delivery system |
Direct injection |
| Fuel type |
Petrol (Gasoline) |
| Valvetrain |
4 |
| Engine aspiration |
Twin-Turbo, Intercooler |
| Engine oil liters | quarts |
5.8 l
6.13 US qt | 5.1 UK qt
|
| Engine coolant |
16.4 l
17.33 US qt | 14.43 UK qt
|
| Powertrain architecture |
Internal Combustion engine |
| Engine location |
Front, Longitudinal
|
Transmission and Drive system
| Drive configuration |
All wheel drive (4x4)
|
Brakes
| Front brakes |
Disc |
| Rear brakes |
Disc |
| Anti-lock brake system |
ABS (Anti-lock braking system) |
Steering
| Steering type |
Steering rack and pinion |
Suspension
| Front suspension |
Independent, Spring McPherson, with stabilizer |
| Rear suspension |
Independent, spring multi-link with stabilizer |
Wheels & Tyres
| Wheels size |
255/65 R18; 255/55 R20; 275/45 R21
|
| Wheels rims |
18; 20; 21 |
Passenger
| Passengers seats |
6 |
| Trunk space min liter | cu. Ft. |
515 l
18.19 cu. ft.
|
| Trunk space max liter | cu. Ft. |
2485 l
87.76 cu. ft.
|
Dimensions
| Overall length mm - inch |
5062 mm
199.29 in.
|
| Overall width mm -inch |
2004 mm
78.9 in.
|
| Overall height mm -inch |
1783 mm
70.2 in.
|
| Wheelbase mm - inch |
3025 mm
119.09 in.
|
| Track width front mm - inch |
1699 mm
66.89 in.
|
| Track width rear mm - inch |
1699 mm
66.89 in.
|
Weights
| Curb weight kg -lbs total |
2115 kg
4662.78 lbs.
|
| Fuel tank liters | gallons |
76 l
20.08 US gal | 16.72 UK gal
|
Engine type
6 CYLINDER V-Engine
