Hatchback, 03-mag Doors, 5 Seats
6.5 l/100 km 36.19 US mpg
70 Hp @ 4500 rpm.
39.9 Hp/l
163 km/h 101.28 mph
1753 cm3
106.97 cu. in.
4, Inline
Front wheel drive,
4104 mm
161.57 in.
1691 mm
66.57 in.
1095 kg
2414.06 lbs.
| Brand | Ford |
|---|---|
| Model | Escort (Hatchback) |
| Version | Escort VII Hatch (GAL,AFL) |
| Engine version | 1.8 TD (70 Hp) |
| Year production start | 1996 |
| Year production end | 1999 |
| Vehicle type | Hatchback |
| Horsepower RPM | 70 Hp @ 4500 rpm. |
| Curb weight kg -lbs total |
1095 kg2414.06 lbs. |
| Overall length mm - inch |
4104 mm161.57 in. |
| Doors | 03-mag |
| Top Speed | 163 km/h 101.28 mph |
| Cam configuration | OHC |
|---|---|
| Engine position and orientation | Front, Transverse |
| Cylinders | 4 |
| Position of cylinders | Inline |
| Displacement (liters) |
1753 cm3106.97 cu. in. |
| Eng. horsepower RPM | 70 Hp @ 4500 rpm. |
| Horsepower per litre | 39.9 Hp/l |
| Weight / horsepower kg/hp - hp/tons |
15.6 kg/Hp63.9 Hp/tonne |
| Weight / torque kg/Nm - Nm/tons | 8.1 kg/Nm, 123.3 Nm/tonne
8.1 kg/Nm123.3 Nm/tonne |
| Torque Nm RPM lb-ft RPM |
135 Nm @ 2500 rpm.99.57 lb.-ft. @ 2500 rpm. |
| Bore (mm in) |
82.5 mm3.25 in. |
| Stroke (mm in) |
82 mm3.23 in. |
| Compression ratio | 21.5 |
| Fuel delivery system | Diesel - Standard diesel injection (SDI) |
| Fuel type | Diesel |
| Valvetrain | 2 |
| Engine aspiration | Turbocharger |
| Powertrain architecture | Internal Combustion engine |
| Engine location | Front, Transverse |
| Drive configuration | Front wheel drive |
|---|---|
| Transmission | 5 |
| Front brakes | Ventilated discs |
|---|---|
| Rear brakes | Drum |
| Anti-lock brake system | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
|---|
| Front suspension | Wishbone |
|---|---|
| Rear suspension | Helical spring |
| Wheels size | 175/70 R13 T |
|---|
| Passengers seats | 5 |
|---|---|
| Trunk space min liter | cu. Ft. |
380 l13.42 cu. ft. |
| Trunk space max liter | cu. Ft. |
735 l25.96 cu. ft. |
| Overall length mm - inch |
4104 mm161.57 in. |
|---|---|
| Overall width mm -inch |
1691 mm66.57 in. |
| Overall height mm -inch |
1398 mm55.04 in. |
| Wheelbase mm - inch |
2525 mm99.41 in. |
| Track width front mm - inch |
1440 mm56.69 in. |
| Track width rear mm - inch |
1462 mm57.56 in. |
| Curb weight kg -lbs total |
1095 kg2414.06 lbs. |
|---|---|
| Gross weight kg -lbs total |
1600 kg3527.4 lbs. |
| Capacities kg - lbs |
505 kg1113.33 lbs. |
| Fuel tank liters | gallons |
55 l14.53 US gal | 12.1 UK gal |
| Combined l/100 km - Mpg |
6.5 l/100 km36.19 US mpg |
|---|---|
| Autonomy km (combined use) | 846 |
