Key specs
Acura TSX (Station wagon (estate)) TSX Sport Wagon 2010,2011,2012,2013,2014
What is the body type, Acura-TSX Sport Wagon-2.4 (201 Hp)-2010?
Station wagon (estate), 5 Doors, 5 Seats
What is the fuel economy, Acura-TSX Sport Wagon-2.4 (201 Hp)-2010?
9.4 l/100 km 25.02 US mpg
10.7 l/100 km 21.98 US mpg
7.8 l/100 km 30.16 US mpg
How much power, Acura-TSX Sport Wagon-2.4 (201 Hp)-2010?
201 Hp @ 7000 rpm.
What is the engine size, Acura-TSX Sport Wagon-2.4 (201 Hp)-2010?
2354 cm3
143.65 cu. in.
How many cylinders, Acura-TSX Sport Wagon-2.4 (201 Hp)-2010?
4,
Inline
What is the drivetrain, Acura-TSX Sport Wagon-2.4 (201 Hp)-2010?
Front wheel drive,
How long is this vehicle, Acura-TSX Sport Wagon-2.4 (201 Hp)-2010?
4805 mm
189.17 in.
How wide is the vehicle, Acura-TSX Sport Wagon-2.4 (201 Hp)-2010?
1840 mm
72.44 in.
What is the curb weight, Acura-TSX Sport Wagon-2.4 (201 Hp)-2010?
1626 kg
3584.72 lbs.
Acura TSX (Station wagon (estate)) TSX Sport Wagon 2010,2011,2012,2013,2014 Specs
General information
| Brand |
Acura |
| Model |
TSX (Station wagon (estate)) |
| Version |
TSX Sport Wagon |
| Engine version |
2.4 (201 Hp) |
| Year production start |
2010 |
| Year production end |
2014 |
| Vehicle type |
Station wagon (estate) |
| Horsepower RPM |
201 Hp @ 7000 rpm. |
| Curb weight kg -lbs total |
1626 kg
3584.72 lbs.
|
| Overall length mm - inch |
4805 mm
189.17 in.
|
| Doors |
5 |
Engine specs
| Designation model |
K24Z3 |
| Cam configuration |
DOHC
|
| Engine position and orientation |
Front, Transverse |
| Cylinders |
4 |
| Position of cylinders |
Inline |
| Displacement (liters) |
2354 cm3
143.65 cu. in.
|
| Eng. horsepower RPM |
201 Hp @ 7000 rpm.
|
| Weight / horsepower kg/hp - hp/tons |
8.1 kg/Hp
123.6 Hp/tonne
|
| Weight / torque kg/Nm - Nm/tons |
7.1 kg/Nm, 141.5 Nm/tonne
7.1 kg/Nm
141.5 Nm/tonne
|
| Torque Nm RPM lb-ft RPM |
230 Nm @ 4300 rpm.
169.64 lb.-ft. @ 4300 rpm.
|
| Compression ratio |
11 |
| Fuel delivery system |
Direct injection |
| Fuel type |
Petrol (Gasoline) |
| Valvetrain |
4 |
| Engine aspiration |
Naturally aspirated engine |
| Engine oil liters | quarts |
4.0 l
4.23 US qt | 3.52 UK qt
|
| Engine coolant |
6.3 l
6.66 US qt | 5.54 UK qt
|
Transmission and Drive system
| Drive configuration |
Front wheel drive
|
Brakes
| Front brakes |
Ventilated discs |
| Rear brakes |
Ventilated discs |
| Brake control |
Disc |
| Anti-lock brake system |
ABS (Anti-lock braking system) |
Steering
| Steering type |
Steering rack and pinion |
| Turning diameter m - ft |
11.2 m
36.75 ft.
|
Suspension
| Front suspension |
Double wishbone |
| Rear suspension |
Independent, spring multi-link with stabilizer |
Wheels & Tyres
| Wheels size |
P225/50 R17 93V
|
| Wheels rims |
7.5J x 17 |
Passenger
| Passengers seats |
5 |
| Trunk space min liter | cu. Ft. |
892 l
31.5 cu. ft.
|
| Trunk space max liter | cu. Ft. |
1875 l
66.22 cu. ft.
|
Dimensions
| Overall length mm - inch |
4805 mm
189.17 in.
|
| Overall width mm -inch |
1840 mm
72.44 in.
|
| Overall height mm -inch |
1470 mm
57.87 in.
|
| Wheelbase mm - inch |
2705 mm
106.5 in.
|
| Track width front mm - inch |
1580 mm
62.2 in.
|
| Track width rear mm - inch |
1580 mm
62.2 in.
|
Weights
| Curb weight kg -lbs total |
1626 kg
3584.72 lbs.
|
| Fuel tank liters | gallons |
70 l
18.49 US gal | 15.4 UK gal
|
Fuel economy
| City l/100km - mpg |
10.7 l/100 km
21.98 US mpg
|
| Highway l/100 km - mpg |
7.8 l/100 km
30.16 US mpg
|
| Combined l/100 km - Mpg |
9.4 l/100 km
25.02 US mpg
|
| Autonomy km (combined use) |
745 |
Engine type
4 CYLINDER INLINE
