Key specs
Acura TSX (Sedan) TSX I (CL9) 2003,2004,2005,2006,2007,2008
What is the body type, Acura-TSX I (CL9)-2.4 i 16V (203 Hp)-2003?
Sedan, 4 Doors, 5 Seats
How much power, Acura-TSX I (CL9)-2.4 i 16V (203 Hp)-2003?
203 Hp @ 6800 rpm.
86.2 Hp/l
What is the engine size, Acura-TSX I (CL9)-2.4 i 16V (203 Hp)-2003?
2354 cm3
143.65 cu. in.
How many cylinders, Acura-TSX I (CL9)-2.4 i 16V (203 Hp)-2003?
4,
Inline
What is the drivetrain, Acura-TSX I (CL9)-2.4 i 16V (203 Hp)-2003?
Front wheel drive,
How long is this vehicle, Acura-TSX I (CL9)-2.4 i 16V (203 Hp)-2003?
4657 mm
183.35 in.
How wide is the vehicle, Acura-TSX I (CL9)-2.4 i 16V (203 Hp)-2003?
1762 mm
69.37 in.
What is the curb weight, Acura-TSX I (CL9)-2.4 i 16V (203 Hp)-2003?
1495 kg
3295.91 lbs.
Acura TSX (Sedan) TSX I (CL9) 2003,2004,2005,2006,2007,2008 Specs
General information
| Brand |
Acura |
| Model |
TSX (Sedan) |
| Version |
TSX I (CL9) |
| Engine version |
2.4 i 16V (203 Hp) |
| Year production start |
2003 |
| Year production end |
2008 |
| Vehicle type |
Sedan |
| Horsepower RPM |
203 Hp @ 6800 rpm. |
| Acceleration 0 - 100 kmh sec |
7.5 sec |
| Curb weight kg -lbs total |
1495 kg
3295.91 lbs.
|
| Overall length mm - inch |
4657 mm
183.35 in.
|
| Doors |
4 |
Engine specs
| Designation model |
K24A2 |
| Engine position and orientation |
Front, Longitudinal |
| Cylinders |
4 |
| Position of cylinders |
Inline |
| Displacement (liters) |
2354 cm3
143.65 cu. in.
|
| Eng. horsepower RPM |
203 Hp @ 6800 rpm.
|
| Horsepower per litre |
86.2 Hp/l
|
| Weight / horsepower kg/hp - hp/tons |
7.4 kg/Hp
135.8 Hp/tonne
|
| Weight / torque kg/Nm - Nm/tons |
6.6 kg/Nm, 150.5 Nm/tonne
6.6 kg/Nm
150.5 Nm/tonne
|
| Torque Nm RPM lb-ft RPM |
225 Nm @ 4500 rpm.
165.95 lb.-ft. @ 4500 rpm.
|
| Bore (mm in) |
87 mm
3.43 in.
|
| Stroke (mm in) |
99 mm
3.9 in.
|
| Compression ratio |
10.5 |
| Fuel delivery system |
Multi-point indirect injection |
| Fuel type |
Petrol (Gasoline) |
| Valvetrain |
4 |
| Engine aspiration |
Naturally aspirated engine |
| Engine oil liters | quarts |
4.2 l
4.44 US qt | 3.7 UK qt
|
| Engine coolant |
5.4 l
5.71 US qt | 4.75 UK qt
|
Transmission and Drive system
| Drive configuration |
Front wheel drive
|
| Transmission |
6 |
Brakes
| Front brakes |
Ventilated discs |
| Rear brakes |
Ventilated discs |
| Brake control |
Disc |
| Anti-lock brake system |
ABS (Anti-lock braking system) |
Steering
| Steering type |
Steering rack and pinion |
Suspension
| Front suspension |
Coil spring |
| Rear suspension |
Helical spring |
Passenger
| Passengers seats |
5 |
| Trunk space min liter | cu. Ft. |
354 l
12.5 cu. ft.
|
Dimensions
| Overall length mm - inch |
4657 mm
183.35 in.
|
| Overall width mm -inch |
1762 mm
69.37 in.
|
| Overall height mm -inch |
1456 mm
57.32 in.
|
| Wheelbase mm - inch |
2670 mm
105.12 in.
|
| Track width front mm - inch |
1515 mm
59.65 in.
|
| Track width rear mm - inch |
1515 mm
59.65 in.
|
Weights
| Curb weight kg -lbs total |
1495 kg
3295.91 lbs.
|
| Fuel tank liters | gallons |
65 l
17.17 US gal | 14.3 UK gal
|
Engine type
4 CYLINDER INLINE
